Controls C3M-2514-AS User Manual

12
CONFIGURATION MENUS
(1)
Input Configuration
Digital Input 1 – Pre Set to Auto Start
(2)
Output Configuration
Relay Output 1 – Pre Set to Start Alarm
Relay Output 2 - Pre Set to Fuel/Run
Relay Output 3 - Pre Set to Preheat
Relay Output 4 - Pre Set to Crank Signal
(3)
Throttle Configuration
Throttle Type - Throttle Type Selection (Default = Off)
(4)
Engine Safety Configuration
Pressure and Temperature Units (Default = English)
Sender Check Bypass Time Period Selection (Default = 10 Sec.)
Fuel Sender Type (Default = Switch)
Fuel Level Check (Off / Always / Run)
Low Fuel Level Pre-Alarm % Selection (Default = 20%)
Low Fuel Level Alarm % Selection (Default = 1%)
Fuel Alarm Time Delay Selection (Default = 1 Sec.)
Oil Pressure Sender Type (Default = S-W)
Oil Pressure Check (Off / Always / Run)
Low Oil Pressure Pre Alarm % Selection (Default = 15 psi)
Low Oil Pressure Alarm % Selection (Default = 10 psi)
Oil Pressure Alarm Time Delay Selection (Default = 5 Sec.)
Engine Temperature Sender Type (Default = S-W)
Engine Temperature Check (Off / Always / Run)
Engine Temperature Pre Alarm Selection (Default = 220 deg. F)
Engine Temperature Alarm Selection (Default = 230 deg. F)
Engine Temperature Alarm Time Delay Selection (Default = 5 Sec.)
Battery Volt Check On/Off
Low Battery Volt Pre Alarm Selection
High Battery Volt Pre Alarm Selection
Battery Volt Trim Setting
Over Speed Alarm On/Off
Over Speed Alarm RPM Setting
