Controls EMGRT1 User Manual

CONTROLS, INCORPORATED
CONTROL SYSTEMS & SOLUTIONS
- 4 -
3) Enclosure
3.1 The product is housed in an 8”W x 8”H x 4”D polycarbonate enclosure that is rated NEMA 4X.
3.2 The enclosure is hinged. Door is held by four screws that are removable for internal access.
3.3 The controller is plug & play with all engine and accessory connectors incorporated into the enclosure.
These connections include:
• Engine Harness Connector – 16 Pin Deutsch Plug
• Float Connector – Pollack Single / Dual Float. Use two normally open contacts
which when both closed will start the engine. When the low contact open, the
engine will stop.
Engine Harness
Connector
Dual Float
Connector
