2) Interface
2.1 Display – The backlit digital display is 1”H x 4”W with two rows of 16 characters. Character height is
approximately ½”.
2.2 Display Parameters – The six full-time display parameter are:
· Water Temperature (Degrees F) · Battery Voltage
· Engine RPM · Fuel Level (if fuel level sender installed)
· Oil Pressure (PSI) · Engine Hours
2.3 Menu & Enter Buttons – To access and scroll menus.
2.4 Up / Down Buttons – For menu navigation.
2.5 Key Switch – Auto / Off / Run
2.6 Fuse – 10 amp fuse
2.7 Amber (Pre Alarm) LED and Red (Alarm) LED located above the digital display.
Digital
Display
10 Amp
Fuse
Auto/Off/Run
Key Switch
Keypad
Buttons
