Main Menus
Main Menus
Sub Menus
Active Engine Fault Codes
View/Scroll Active Fault Codes
Stored Engine Fault Codes
View/Scroll Stored Fault Codes
Engine Parameters
View ECU Engine Information
(% Load, Torque, Oil Temp, etc.)
Emissions Parameters
Regen Options (Auto, Inhibit, Request)
DEF Level
DPF Soot Load % View
DPF Ash Load % View
Regen Active/Not Active View
Regen Inhibited/Not Inhibited View
DPF Out Gas Temperature View
DPF Differential Pressure View
Operation Event Log
View Last 32 Events (Start, Stop, Alarms)
Alarms Event Log
View Last 32 ECU and Controller Alarms)
Engine Identification
Engine Model # View
Engine Serial # View
Module Information
Control Unit Part# View
Control Unit Software Version View
Controller Setup Menus
Quick Setup
(1)
(PASSWORD PROTECTED)
Engine Parameter Configuration
(2)
Input Configuration
(3)
Output Configuration
(4)
Throttle Configuration
(5)
Engine Safety Configuration
(6)
Module Configuration
(7)
Display Configuration
(8)
CAN Configuration
(9)
Auto Shutdown Configuration
(10)
Maintenance Configuration
(11)
Emissions Configuration
(12)
Modbus Configuration
(13)
Clutch Configuration
(14)
Configuration
Menus
Viewing Menus
