Convotherm OGS 20.20 Manual

2. Positioning
37
EN
Gas appliances
OGS / OGB 6.10: 155/ 175kg
OGS / OGB 6.20: 215/ 235 kg
OGS / OGB 10.10: 173/ 200 kg
OGS / OGB 10.20: 250/280 kg
OGS / OGB 12.20: 320/*342* kg
OGS / OGB 20.10: 315*/344* kg
OGS / OGB 20.20:404*/458* kg
* = including loading trolley
Electrical appliances
OES / OEB 6.10: 136/155 kg
OES / OEB 6.20: 196/215 kg
OES / OEB 10.10: 165/175 kg
OES / OEB 10.20: 225/245 kg
OES / OEB 12.20: 288*/314* kg
OES / OEB 20.10: 295*/315* kg
OES / OEB 20.20:395*/414* kg
* = including loading trolley
2.1 Prerequisites for Installation
Site
• Does the combi steamer fit through
passageways and doors? Indication
for minimum measures of a unit on a
pallet without packing.
• Unit dimensions (Width x Depth x
Height) with packing (in mm) see
below.
• Installation site surface
– The installation surface must be
even and level.
– The installation site must be able to
hold the weight of the unit (see
below) and the maximum load (see
Operator's Manual).
• Climate conditions at the installation
site:
– Must be in accordance with Work
Place-Decree!
– The area temperature must only be
+4°C to +35°C.
– Do not operate in a poisonous or
explosive atmosphere.
– Do not operate outdoors without
protection from rain.
• Do not place the combi steamer near
cooking units such as fryers or units
baking with grease etc.. There is a
high risk of burns to the user when
water sprays in hot grease.
A safety distance must be
maintained from grease holders or
fryers (the working radius of the
hand shower).
• For sea water conditions, use special
units with option ‚marine version’.
• Do not install the unit next to flammable
materials. The local fire safety
regulations must be adhered to!
2.2 Transport to Installation
site
• Transport on pallet only!
• Unit should be moved in upright
position!
• An inventory/packing list is under the
top of the packing carton.   .
• Remove all cartons, packing material,
documents, labels, containers and
loading trolley etc. from the oven.
2.3 Remove unit from the pallet
• Using a high lift truck, lift combi
steamer from the pallet. Do not tip!
• If necessary, use a low lift platform
truck or forklift for bringing the unit into
the right position.
• Before picking the unit up with a forklift
or low lift truck, it is necessary to pay
attention to the correct position of
the lifting forks (stay right of drain (C)
and unit overflow (M)!)
X.10  C = 283 mm / M = 337 mm
X.20  C = 323 mm / M = 375 mm
Electrical appliances & Gas appliances
CONVOTHERM 6.10: 1,130x950x1,040
CONVOTHERM 6.20: 1,410x1,175x1,105
CONVOTHERM 10.10: 1,130x950x1,310
CONVOTHERM 10.20: 1,410x1,175x1,330
CONVOTHERM 12.20: 1,435x1,200x1,650
CONVOTHERM 20.10: 1,150x1,000x2,185
CONVOTHERM 20.20: 1,435x1,200x2,185
Picture 1
Picture 2
Picture 3/4
Picture 3/4
Picture 3/4
Picture 7
