MX2N series HMI PLC all in one programming manual
16
timeout flag
M8014
1m clock pulse
M8140
ZRN Instruction clear output is
valid
M8015
Set clock
M8145
Prohibit Y0 pulse output
M8016
Clock display stopped
M8146
Prohibit Y1 pulse output
M8017
Clock ±30 s correction
M8147
Y0 in Pulse output
M8018
Real clock flag
M8148
Y1 in Pulse output
M8019
Clock error flag
M8149
CAN communication timeout
M8020
Zero flag
M8150
CAN allowed working flag
M8021
Borrow flag
M8155
Prohibit Y2 pulse output
M8022
CF (carry flag)
M8157
Y2 Pulse in output
M8029
Instruction execution end
M8158
Y3 Pulse in output
M8031
Non-Latch data clear
M8161
16-bit/8-bit switch flag
M8032
Latch data clear
M8168
SMOV instruct HEX
processing function
M8034
Prohibit all outputs
M8170
X0 Pulse capture
M8039
Constant scanning mode
M8171
X1 Pulse capture
M8047
STL Effective monitoring
M8172
X2 Pulse capture
M8048
S900-S999 -"ON "
M8173
X3 Pulse capture
M8049
Valid signal alarms
M8174
X4 Pulse capture
M8050
I0 口口 Interruption prohibition
M8175
X5 Pulse capture
M8051
I1 口口 Interruption prohibition
M8196
C251 C252 C254 2 multiplier
M8052
I2
口口
Interruption prohibition
M8197
C253 C255 2 multiplier flag
M8053
I3
口口
Interruption prohibition
M8198
C251 C252 C254 4 multiplier
M8054
I4 口口 Interruption prohibition
M8199
C253 C255 2 multiplier flag
M8055
I5 口口 Interruption prohibition
M8200~
M8234
C200-C234 count direction set
M8074
Optional External Digital
Tube/key Single/Dual Display
Mode
M8235~
M8345
C235-C245 count direction set
M8075
Optional external digital
tube/key low 6-bit ,decoding
Optional external digital
tube/key high 4-bit ,decoding
M8246~
M8255
C246-C255 count direction
flag
M8076
Optional external digital
tube/button low 6-bit register
display selection
Optional external digital
tube/button height 4-digit
register display selection
