MX2N series HMI PLC all in one programming manual
5 Random number instructions
1) Random number related register: Start convert relay-M8005
Random number save register-D8005 (low) D8006 (high)
2) If you need to generate the random number, just need to set M8005 ON in the program.
When the random number is generated and be saved to D8005 D8006, M8005 will be set OFF
automatically.
3) Therefore, M8005 is set from OFF to ON, then start the random number conversion.
And M8005 turn from ON to OFF, then the conversion is completed.
4)
M8005 ‘s Down －Conversion completed
Extract random numbers to D0 D1
