MX2N series HMI PLC all in one programming manual
8 High speed pulse output application
1) Normally with two high-speed pulses (Y0 and Y1), pulse transmission single channel
maximum frequency: 100Khz, dual channel maximum: 30Khz; maximum optional four-way
high-speed pulse, Y0 and Y1 can output 200KHZ at the same time, Y2 and Y3 can output
100KHz at the same time;
2) Regarding the positioning command with direction output: after driving, the direction
output delay is 20ms before outputting the pulse;
3) Special components used for pulse instructions:
Min output
frequency（default：
0）
Acceleration time
（default：100ms）
Output pulse stops
immediately
