cumulative time limit.
◆ Support function of NTC thermistor to measure temperature,support NTC of
10K,50K,B value of 3950.
◆ Support optional digital tube display function, support 24keys input,10 common
positive digital display,you can choose dingle and double bits display,or whether to
decode the display.
◆ MX2N-70HB is optional to add 1 channel load cell function (occupy AD0-AD2).
1.2 Type & Specification
Type
MX2N-43HB
MX2N-70HB
Dimension
134*102*30mm
212*148*40mm
Cutout size
120*94mm
194*138mm
HMI
Features
60K colors resistive panel
Display size
97*56mm
154*87mm
Resolution
（pixels）
480*272
800*480
RAM
32MB
64MB
ROM
128MB
Operation
system
NULL
CPU
ARM9 216MHz
ARM9 288MHz
COM port
1 TP download port,1 USB port
1 RS232 /1 RS485 optional
Software
CoolMayHMI V5.**(newest vesion pls see HTTP://coolmay.net)
PLC
