MX2N series HMI PLC all in one programming manual
5
Digital I/O
12DI/12DO
24DI/20DO
I/O level
NPN,COM
Output type
MT
（
MOS) : 2A at most / MR (Relay): 5A at most
High speed
Counting
Normally 6 single phase counting (X0-X5) or 2 AB phase counting
（
X0-X1/X3-X4
）
10KHz
High speed
Counting
At most 6 single counting can be customized (4 60KHz、2 10KHz)
or 2 AB phase counting( 2 60KHz)
High speed
Pulse
Normally 4 channels 20KHz，Y0-Y3
2 channels 200KHz and 2 channels 100KHz can be customized
Analog I/O
AI: 0-5V/0-10V/0-20mA/NTC10K/NTC50K/EKJ
Note: NTC type needs to occupy AD4 as a common terminal;
optional EKJ thermocouple has only 2 channels, which occupies
AD4~AD7; (NTC type and thermocouple type cannot coexist)
AO:0-10V/0-5V/0-20mA or mixed
Optional voltage and current could be done 4 channels at most.
4AD/2DA
8AD/2DA
Optional 1 channel load cell
(occupy AD0-AD2)
Com port
Default with rs232 programming port
null
Optional 1 485 (can not
coexist with its default rs232,
not suggest to change rs232 to
be rs485)
Software
Compatible with MITSUBISHI GX8.52 and WORKS2
Regular Models:MX2N-43HB-16MR/24MR/24MT(-4AD2DA-232H)
MX2N-70HB-44MR/44MT(-8AD2DA-485P/232H)
485P= PLC to add 485
；
485H/232H= HMI to add 485/232
Detailed info. refer to: <Coolmay MX2N Series PLC Programming Manual>
<HMI PLC All In One User Manual> <Coolmay HMI User Manual>
