MX2N series HMI PLC all in one programming manual
1st to 8th activity STL status
Shared register
number（1~32, Default：8）
Minimum activity STL status
CAN Communication baud rate
(20K~100K, Default
：
250K)
Y2 Pulse output count register
Y3 Pulse output count register
Optional external digital
tube/key,Brightness
(Setting:0~7,Default1)
ZRN\DRVI\DRVA command
Y2 Y3 minimum speed
Optional External Digital
Tube/Key Low 6-bit
Flashing Register
ZRN\DRVI\DRVA command
Y2 Y3 maximum speed
Optional External Digital
Tube/Key Low 6-digit
Decimal Point Position
Register
ZRN\DRVI\DRVA command
Y2 Y3 acceleration and
deceleration time
Optional external digital
tube/button High 4-digit
flash register
Y2 Y3 High-speed output
count:32 bit
Optional External Digital
Tube/Key High 4-digit
decimal point position register
Z1 Address register contents
Optional external digital
tube/key,show register
V1 Address register contents
Sampling filter numbers
（0-22，Default 0）
Z2 Address register contents
Thermocouple type
（K-0,E-1,J-2）
V2 Address register contents
Thermocouple cold junction
temperature
Z3 Address register contents
1st thermocouple Temperature
V3 Address register contents
Temperature of second
thermocouple
Z4 Address register contents
Analog DA0 Output
data(0~4095)
V4 Address register contents
Analog DA1 Output
data(0~4095)
Z5 Address register contents
V5 Address register contents
Z6 Address register contents
V6 Address register contents
Z7 Address register contents
