Revised: 15/02/16 31/03/2016
16
CLEAR VIEW DOUBLE SIDED – FOR MAXIMUM WALL THICKNESS - 248MM
The flue outlets are factory set to accommodate plaster board, this can be adjusted to
accept 30mm. i.e allowance for tiles.
To adjust take off the plate, undo 4 screws, slide the spigot forward, then tighten screws.
Make sure screws are tight and the unit is sealed. Put cover plate back on and silicone.
This operation needs to be done prior to installation.
SPIGOT
PLATE
