Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
09 1 0 YES 45.0 1.8 0.1 Reclose #3 (seconds) 5
• Reclose #3 is the open time duration after the
third trip operation prior to automatic reclosing.
• Selects the reclose interval after the third trip
operation.
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
08 1 0 YES 45.0 1.8 0.1 Reclose #2 (seconds) 2
• Reclose #2 is the open time duration after the
second trip operation prior to automatic reclosing.
• Selects the reclose interval after the second trip
operation.
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
07 1 0 YES 45.0 0.3 0.1 Reclose #1 (seconds) 2
• Reclose #1 is the open time duration after the
first trip operation prior to automatic reclosing.
• Selects the reclose interval after the first trip
operation.
Programming (cont’d)
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
06 1 0 YES 180 3 1 Reset Time (seconds) 30
• Reset timing begins after a successful reclose
operation.
• Successful reclose is determined when the
recloser is closed and the current sensed is
below the minimum trip values (phase and
ground).
To Next Page
