46
Kyle Form 4C Microprocessor-Based Recloser Control Programming Guide
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
132 1 0 YES 30 1 -- High-Current Trip - Phase 30
(Multiples of Minimum Trip)
132 1 0 YES 30 1 -- High-Current Trip - Ground 30
(Multiples of Minimum Trip)
• Sets the operating level (in multiples of minimum
trip) at which the recloser will trip when the fault cur-
rent is above the programmed level.
• Operating levels are separately selectable from 1 to
30, in increments of 1, for phase and ground trip.
• Use the PHASE/GROUND key to examine phase or
ground.
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
131 1 0 YES -- -- -- High-Current Trip - Ground (ON/OFF) OFF
• High-Current Tripping allows for tripping the recloser
with a programmable constant time whenever fault
current exceeds a programmed level.
• High-Current Tripping is used to modify the time–
current curve to allow for increased coordination
with primary substation transformer protection or
coordination with load side fusing.
• Trips a recloser at any current above the selected
fault current level. Levels are set as multiples of the
minimum trip (see Access Code 132).
• High-Current Trip-Ground is operable for phase and
ground combined. It does not operate for ground
only.
• Select High-Current Trip-Ground ON and OFF using
the CHANGE key.
High-Current Trip
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
130 1 0 YES -- -- -- High-Current Trip - Phase (ON/OFF) OFF
• High-Current Tripping allows for tripping the recloser
with a programmable constant time whenever fault
current exceeds a programmed level.
• High-Current Tripping is used to modify the time
current curve to allow for increased coordination
with primary substation transformer protection or
coordination with load side fusing.
• Trips a recloser at any current above the selected
fault current level. Levels are set as multiples of the
minimum trip (see Access Code 132).
• High-Current Trip-Phase is operable for phase or for
phase and ground combined.
• Select High-Current Trip-Phase ON and OFF using
the CHANGE key.
To Next Page
