If substantial work is required, beyond the scope of the inspection, survey the exact requirements, identify
cause, and take full details for report to client.
Leave “Call Report” at site to advise of situation.
8.3 Replacement Parts
8.3.1 Fuse Replacement
CAUTION 230Vac input voltage. Qualified personnel to BS 7671 IEE Wiring Regulations
only.
All replacement fuses must be of the same size, current, rating and type as the original.
Internal Fuses:
F1(PCB) F100mA L 250V
F2(PCB) - F100mA L 250V
F3(PCB) - 4A ATO Blade Automotive Fuse
Brake Fuse (inline) - T315mA L 250V
External Fuses:
Mains Fuse (IEC Inlet) - T1A E 250V
Control Fuse - T200mA L 250V
Battery Fuse - T5A L 250V
Accessory Fuse - T1A L 250V
The use of a fuse with a different rating may result in fire, electric shock, or irreparable damage.
8.3.2 Battery Replacement
The batteries must only be replaced with suitable batteries of the same type, voltage and capacity.
Valve Regulated Lead Acid Batteries.
12V.
1.2Ah.
Must be approved for ‘Standby’ applications.
Caution! Incorrect battery connection will damage the PSU.
Connection of unsuitable batteries may result in fire,
electric shock, or irreparable damage.
9 Cleaning
Clean the controller outer surface with a dry cloth only; avoid the use of water or solvents.
