Copley Controls Xenus PLUS - Page 20

Signal Pins Signal Pins
[OUT1+] J9-19 [OUT1-] J9-10
[OUT2+] J9-20 [OUT2-] J9-11
[OUT3+] J9-21 [OUT3-] J9-12
Input State Condition
OUT1~3
HI OutputtransistorisON,currentows
LO OutputtransistorisOFF,nocurrentow
Turnoff
Circuit
[OUTn-]
60mA
max
* at 24 Vdc
Vdc
J9
[OUTn+]
20
400Ω
min*
36V
ASSR-1218
+
+24V
Copley Controls, 20 Dan Road, Canton, MA 02021, USA Tel: 781-828-8090 Fax: 781-828-6547
Tech Support: E-mail: sales@copleycontrols.com, Web: http://www.copleycontrols.com Page 20 of 32
RoHS
Xenus
PLUS
2-Axis EtherCAT
800-1782
OUTPUTCONNECTIONS
CME2SCREENFOROUTPUTS[OUT1~3]
OUTPUTDATA
[OUT1~3]
HI/LODEFINITIONS:OUTPUTS
[OUT1~3]SIGNALS
NOTE: [OUT4] IS NOT AVAILABLE
ON THE 800-18782
+30Vmax
+24Vtypical
