Copley Controls Xenus PLUS - Page 23

Shield
11
10
9
23
20
19
1
18
RESOLVER
INCREMENTAL
NSK VR
Inc B
Inc A
Inc C
Inc Common
RESOLVER
ABSOLUTE
NSK VR
Abs B
Abs A
Abs C
Abs Common
J10
J11
Rslvr Inc B
Rslvr Inc A
Rslvr Inc C
Rslvr Abs A
Rslvr Abs B
Rslvr Abs C
Rslvr Ref(+)
5
TEMP
SENSOR
7
Signal Gnd
Motemp
4
3
2
1
Mot C
Mot B
Mot A
F.G.
J3
J4
J5
2
3
1
+24V
Brake B
4
5
+24V
Brake A
Gnd
+
-
24 Vdc
Axis A
Brake
Axis B
Brake
800-1782
C+
B+
A+
C-
B-
A-
Motor
3 ph.
Note: Motor windings
A-, B-, and C- must be
connected externally.
Copley Controls, 20 Dan Road, Canton, MA 02021, USA Tel: 781-828-8090 Fax: 781-828-6547
Tech Support: E-mail: sales@copleycontrols.com, Web: http://www.copleycontrols.com Page 23 of 32
RoHS
Xenus
PLUS
2-Axis EtherCAT
800-1782
CONNECTIONSFORNSKJSGMOTOR
NOTES:
1) CEsymbolsindicateconnectionsrequiredforCEcompliance.
