Model 491-107

Installation, Operation

& Maintenance Manual

Plain Style Compressors for Liquid

Transfer-Vapor Recovery

Solutions beyond products...

ORIGINAL INSTRUCTIONS IE101K

Warning: (1) Periodic inspection and maintenance of Corken products is essential. (2) Inspection, maintenance and installation of

Corken products must be made only by experienced, trained and qualified personnel. (3) Maintenance, use and installation of Corken

products must comply with Corken instructions, applicable laws and safety standards. (4) Transfer of toxic, dangerous, flammable or

explosive substances using Corken products is at user’s risk and equipment should be operated only by qualified personnel according

to applicable laws and safety standards.

Table of Contents

Questions and Answers:

J
Jennifer LoweAug 17, 2025
Why is the capacity of my Corken F491 Air Compressor so low?
- W
  westjohnAug 17, 2025
  If your Corken Air Compressor has low capacity, several issues could be the cause. The valves might be broken, stuck, or leaking, in which case you should inspect and clean or repair them. A worn piston ring could also be the culprit, so inspect and replace it if necessary. Additionally, a clogged inlet strainer can restrict flow, so clean or replace the screen. Leaks in the piping can also reduce capacity; inspect and repair any leaks. Finally, ensure the 4-way control valve is lubricated by inspecting and lubricating it.
B
Brandy RileyAug 20, 2025
Why is my Corken F491 Air Compressor overheating?
- M
  Meghan RaymondAug 20, 2025
  If your Corken Air Compressor is overheating, several factors could be responsible. Start by checking the valves for any signs of damage, sticking, or leaks; inspect, clean, or repair them as needed. A worn piston ring can also cause overheating, so inspect and replace if necessary. A clogged inlet strainer can also lead to this issue, thus clean or replace the screen as necessary. Ensure that the cooling fins are clean, and clean them weekly. For issues such as high inlet or ambient temperature, high compression ratio, or an unbalanced load, it is recommended to consult the factory.
T
Thomas JenkinsAug 23, 2025
What to do if my Corken Air Compressor has product leakage?
- A
  Alicia McgeeAug 23, 2025
  If you're experiencing product leakage from your Corken Air Compressor, there are a few potential causes. Check for leaks in the piping and repair them as needed. A worn piston-rod packing can also cause leakage, so replace it. Loose valves, pistons, or packing can also be responsible; tighten or replace them as necessary. Additionally, a 4-way control valve that is not lubricated can lead to leakage; inspect and lubricate it.
J
John ContrerasAug 26, 2025
How to fix knocks, rattles, and noise in my Corken Air Compressor?
- T
  Teresa JeffersonAug 26, 2025
  Excessive noise in your Corken Air Compressor can stem from several sources. Valves that are broken, stuck, or leaking are a common cause; inspect, clean, or repair them. A loose flywheel or belt can also generate noise, so tighten them. If the wrist pin or wrist-pin bushing is worn, replace it. Similarly, a worn connecting-rod bearing should be replaced. An unbalanced load may also lead to noise, in this case inspect the valve or consult the factory.
T
tboydAug 28, 2025
How to reduce excessive vibration in my Corken F491 Air Compressor?
- K
  Kathleen AllisonAug 28, 2025
  Excessive vibration in your Corken Air Compressor may be due to several reasons. Broken, stuck, or leaking valves can cause vibration, so inspect, clean, or repair them. A loose flywheel or belt can also lead to vibration, so ensure these are tightened. Worn wrist pins or wrist-pin bushings and worn connecting-rod bearings can also cause vibration and should be replaced. An unbalanced load may also be the cause, in this case inspect the valve or consult the factory. Inadequate compressor base can cause excessive vibration, so you should strengthen, replace, or grout it.
S
Shane HarrisAug 31, 2025
What causes abnormal piston-ring wear in a Corken F491 Air Compressor?
- N
  Nicholas WellsAug 31, 2025
  Abnormal piston-ring wear in your Corken Air Compressor can be attributed to several factors. Valves that are broken, stuck, or leaking can cause this issue, so inspect, clean, or repair them. A worn piston ring itself can also lead to abnormal wear, so inspect and replace it if necessary. Loose valves, pistons, or packing can contribute to this problem; tighten or replace them as needed. Dirty cooling fins can also cause abnormal wear, so clean them weekly. For issues such as high inlet or ambient temperature, high compression ratio, or an unbalanced load, it is recommended to consult the factory.
M
Molly FosterSep 2, 2025
Why is there oil in the cylinder of my Corken F491?
- S
  shanemarksSep 2, 2025
  If you find oil in the cylinder of your Corken Air Compressor, it could be due to a worn piston-rod packing, which should be replaced. Alternatively, the valve, piston, or packing might be loose; tighten or replace these components as necessary.
C
Christopher SmithSep 8, 2025
Why is product leaking through the crankcase breather of my Corken F491?
- K
  Kristin MontgomerySep 8, 2025
  If product is leaking through the crankcase breather of your Corken Air Compressor, it may be caused by a worn piston-rod packing, which requires replacement. Another potential cause is a loose valve, piston, or packing, which should be tightened or replaced as necessary.
M
Matthew HillSep 12, 2025
What causes oil leakage around the base of my Corken F491?
- P
  Paul ChapmanSep 12, 2025
  If you notice oil leakage around the base of your Corken Air Compressor, it could be due to leaking gas blowing oil from the crankcase, in which case you should tighten the packing. Another possibility is a bad oil seal, which would need to be replaced.
C
Christine MooreSep 13, 2025
What to do if my Corken F491 Air Compressor has no oil pressure?
- J
  Jordan WestSep 14, 2025
  If your Corken Air Compressor has no oil pressure, it could be due to a lack of oil in the crankcase, in which case you should add oil. Alternatively, there may be an oil-pump malfunction, in which case you should see oil-pressure adjustment.
