3.6 TRANSPORTING LOADS
PROHIBITED: It is strictly prohibited to surpass the load capacity limits indicated in
the table on page 16.
3.6.1 Construction Body (Dumper)
The machine is equipped with a “dumper” type body to transport inert and solid
materials, suitable mainly to be used for construction work.
3.6.2 “Farming” Type Body”
Upon request, your machine may be fitted, in place of the “dumper” type body,
with a body that has sides that can be opened, and
is suitable to transport farming materials.
The opening of the sides allows one to enlarge the
loading surface to be able to transport cumbersome
objects. To obtain a larger loading surface, work with
one side at a time as follows (see fig. 56):
• Open two anterior hooks “C”, lower the anterior
side “D” and take it out;;
• Loosen the two wheels “A” positioned under the
• loading surface;
• Take out the two supports “B” from their hous-
ings;
fig. 22 – Farming type body
•
Open the posterior hook “E” and lower the left lateral side “F” making coincide
the notches of the supports in the holes “G”;
•
Repeat the operation on the other side;
•
Be sure that the sides are blocked and position the load so that it will not fall: if
possible tied it.
1.1.2 Mini Loader (ML)
ML 85 is a machine equipped with the "Skid Loader" type arm which in turn can be equipped with
various accessories, all thanks to the quick coupling plate with universal attachment for: Bucket,
forks, auger and all the accessories available in the Cormidi catalog for ML 85. The kit can also be
purchased as an accessory to be installed subsequently and exclusively on ML 85 only by
specialized technicians.
