ATTENTION: When performing the insertion and disengagement operations
of the accessory, always check first that the ground is stable and that the
accessory and the plate are intact and fully functional.
3.9 ELECTRICAL PLUG
Your machine it's equipped with some
devices that make it more
complete. To the side is shown the
position of the 12V DC power outlet (see
fig. 24) that provides power for operation
of electrical devices with additional
features highlighted by
the close label.
3.10 BATTERY RECHARGE
To charge:
•
Open the bonnet
•
connect the (-) battery with the
cable for charging Black
•
connect the (+) battery with the
cable for charging Red
(see sidebar, fig. 25).
fig. 24 – electrical plug 12V
fig. 25 – battery recharge
