3.11 TRANSPORT
WARNING: During transport, always position the machine levelly to avoid
the spilling of oil or other liquids
If the machine needs to be transported, one must proceed correctly to avoid
dangers to persons and/or to the machine, if there is any on the machine, keep
down completely the bucket during the transport. Because of the weight of
the machine, it is not possible to move it man-
ually. Thus, it is necessary to use suitable
means of lifting to load it onto a means of
transport.
The machine is equipped with 4 hooks for lift-
ing each one with a capacity of 7.000N (700kg)
for a total of 28.000N (2.800kg).
The position of each hook is indicated with a
label like the one shown in the fig. 26
fig. 26 – Anchoring point
To do this operation safely you should use, as tools of lifting, 4 ropes with hooks,
CE compliant; the two front ropes are 200cm of length, and the two rear ropes
are 200cm of length, in the following way:
•
Disconnect the battery, turning the device to cut off battery;
•
Empty the fuel tank and close the plug;
•
Fix the lifting hooks exclusively to the anchoring points that were pre-
scribed by the manufacturer (fig. 29);
WARNING: Raise the machine by hooking it exclusively to the hooks pre-
disposed for this purpose: the anchoring of the machine in other points
can cause breakage with the consequent fall of the machine and can
cause serious harm to persons.
