Cornelius 255 - Function; Lid Installation (Without Icemaker)

Adapter Lid For 255/215 - Installation Instructions
©2018, Cornelius Inc. - 3 - Publication Number: 548000078INS
FUNCTION:
• The lid functions as a manual fill lid normally and then can be cut to appropriate score and be an ice
adapter.
CAUTION:
!
Before Installing the Lid, remove the existing cover if present, you will have two paths for the installation, with and
without ice maker on top of the unit.
!
WARNING:
This Kit Is Used Only For 30" Icemaker
LID INSTALLATION (WITHOUT ICEMAKER)
Table 1: Lid Installation (Without Icemaker)
Step Action Figures
1.
Hold the cover with the lid folded on the back
cover and facing down.
Figure 1.
2.
Position the front and the back of the lid, as
shown.
Figure 2.
3.
Place the lid on top of the unit.
Figure 3.
