GENERAL INFORMATION
INTRODUCTION
Cornelius CH Series, Refrigerated Recirculating Water Chillers are designed to provide a continuous flow of clean
cooling water at a constant temperature and to handle a variety of closed loop and tank cooling applications.
The CH Series consists of a refrigeration system with associated operating controls housed in a sturdy sheet metal
cabinet. A standard pump and reservoir package provides a complete self-contained water cooling and circulating
system.
CH Series Chillers are designed to operate in a clean laboratory or industrial environment where ambient
temperatures range from 50
o
F to 100
o
F. Once properly installed, CH Series Chillers run virtually maintenance free
and provide a constant supply of cooling liquid to the application.
Specifications
The CH Series specifications are shown in Ta ble 1.
Specification Notes
1. The figures for power and cooling capacity are listed for air-cooled units with a circulation temperature of
68° F and ambient temperature of 80° F and standard pump.
2. Cooling capacity will be affected as follows: Derate 17% for 50 Hz operation. Derate 1% for each degree
Fahrenheit drop in recirculating temperature. Derate 0.5% for each degree Far en he it increase in ambient
temperature.
3. The operating water temperature range for water is 50°F (10
o
C) to 100°F (38°F). If uses of other fluids or
temperatures are required, the Technical Service Department must be contacted so the appropriate
ranges can be set.
4. All CH Series Chillers are thoroughly tested before leaving the factory to ensure that each unit meets these
specifications prior to shipment.
Table 1.
Model CH1500 CH2000 CH3000
Cooling capacity, Watts/BTU/hr 5861/20000 7033/24000 9964/34000
Compressor 1.5 HP 2 HP 3 HP
Condenser Air Cooled
Temperature Controller
Digital Display 40
o
-100
o
F
Pump
1CS (10 GPM @ 35
PSI)
2CS (12 GPM @ 50 PSI)
Reservoir (Capacity) 10 Gallons
Voltage (Full Load Amps)
CH1502A 230/60/3 (10) CH2002A 230/60/3 (14) CH3002A 230/60/3 (18)
CH1503A 460/60/3 (5) CH2003A 460/60/3 (7) CH3003A 460/60/3 (9)
Dimensions W x D x H (inches) 28 x 28 x 41
Inlet/Outlet Fitting Size 3/4-inch
