Cornwell Tools MMWMP242DVI - Page 43

Page of 44
43
REFERENCE #
PART #
DESCRIPTION
Qty
1
105200228
Handle
1
2
105200047
Gas Valve
1
3
105200211
Power Cable
1
4
105400050
Power Switch
1
5
105500091
Plastic back panel
1
6
155200069
Back panel
1
7
125400016
Power Cord Holder
2
8
165200042
Control PCB board
1
9
165200040
Fan
1
10
165200041
Mainboard
1
11
105200234
PC Board Support
1
12
155200065
Bottom Panel
1
13
105500033
Feet
4
14
155200070
Center Panel
1
15
105200317
Output reactor
1
16
105100075
Hinge
2
17
105500092
Plastic front panel
1
18
105200136
Quick Connect Socket
2
19
105200059
MIG gun switch socket
1
20
105200300
Potentiometer knob(small)
1
21
105200057
MIG Weld Power Cable
1
22
155200066
Flange plate
1
23
155200071
Panel support plate
1
**
155200073
Nameplate Sticker
1
24
165200047
Potentiometer knob(large)
1
25
155200072
LCD control panel
1
26
105200323
Fixed plate of wire feeder
1
27
105200324
Sub-plate of wire feeder
1
28
105800019
MIG Block
1
29
105800020
Wire feeder
1
30
105200009
Spool Hub Adapter
1
**
105200071
Drive Roll (.023V / .030VK)
1
**
105200072
Drive Roll (.030V / .035VK)
1
31
155200067
Enclosure
1
32
155200068
Door
1
33
125200061
Door Latch
1
**Items are not pictured
For replacement parts please call 888-762-4045.
