Correlated Solutions Vic-3D 8 User Manual

Figure 10. Hinge mounted to extrusion
c. Tighten the T-nut with the provided 5mm hex driver so that the hinge is close to the end of the extrusion.
d. Slide the other 23” extrusion piece through the hinge’s other T-nut about halfway so that it is
perpendicular to the already mounted extrusion bar, as seen in Figure 11.
e. Use the 5mm hex driver to tighten the hinge to the extrusion via the remaining T-nut.
f. Manually tighten the handle on the hinge.
