Corsair H100i v2 User Manual

2
Installing the Intel Stando Screws
• Attach the provided Intel stando.
• Use (B) for LGA 115X / 1366, or (C)
for LGA 2011.
• Tighten all four screws until firmly secure.
C
B
LGA2011
LGA 115X/1366
3
Install the Fans and Radiator
Attach the radiator and the fans as shown. For the best
cooling performance, we recommend mounting the fans
as an air-intake to your PC case.
D
E
J

Corsair H100i v2 Specifications

General

Radiator Dimensions	276mm x 125mm x 30mm
Fan Dimensions	120mm x 25mm
Noise Level	37.7 dBA
Radiator Material	Aluminum
Fan Airflow	70.69 CFM
Radiator Size	240mm
Tube Length	300mm
Warranty	5 years
Fan Speed	2435 RPM
Compatibility	Intel LGA 1150, 1151, 1155, 1156, 1366, 2011, 2011-3, AMD AM2, AM3, FM1, FM2
Fan Static Pressure	4.65 mmH2O
Type	Liquid Cooling System
Tubing Material	Low-permeation rubber with black sleeving
