Corsair SF750 User Manual

Short-circuit protection (SCP)
A short-circuit is defined as any output impedance of less than 0.1 ohms. Amongst other things, SCP ensures
that the PSU shuts down should the 3.3V, 5V and 12V rails short to any other rail, or to ground. It also ensures
that no damage should occur to the unit, or your PC’s components in the event of a short.
SF750
DIMENSIONS:
125mm (W) x 63.5 mm (H) x 100mm (L)
PACKAGE CONTENTS:
CORSAIR SF Series power supply unit
AC power cord
DC modular cable set
DC modular cable storage bag
Cable ties
CORSAIR case badge
User manual
SFX to ATX adapter
Important safety information
CORSAIR SF750 POWER TABLE
CORSAIR SF750 POWER SUPPLY EFFICIENCY
CORSAIR SF750 POWER SUPPLY FAN NOISE CURVE

Corsair SF750 Specifications

General

Total power	750 W
AC input voltage	- V
Combined power (-12V)	3.6 W
Combined power (+3.3V)	130 W
Combined power (+5Vsb)	12.5 W
Max output current (+12V)	62.5 A
Max output current (-12V)	0.3 A
Max output current (+3.3V)	20 A
Max output current (+5Vsb)	2.5 A
Cooling type	Active
Fan diameter	92 mm
Product color	Black
Cabling type	Fully-Modular
CPU power cable length	400 mm
SATA power cable length	450 mm
EPS power connector (8-pin)	Yes
Motherboard power connector	24-pin ATX
Floppy drive power connector	0
PCI Express power cable length	500 mm
Number of SATA power connectors	8
PCI Express power connectors (8-pin)	4
Peripheral (Molex) power cable length	330 mm
Peripheral (Molex) power connectors (4-pin)	3
Purpose	PC/server
ATX version	2.4
Bearing technology	Rifle
80 PLUS certification	80 PLUS Platinum
Mean time between failures (MTBF)	100000 h
Continuous output rated temperature	50 °C
Power supply unit (PSU) form factor	SFX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	63 mm
Width	125 mm
Height	100 mm
