Range Dimensions
• Avoid placing cabinetry directly above the appliance when possible. If cabinetry is used above
the cooking surface, use cabinets no more than 13″ deep. Make sure the wall coverings, countertop
and cabinets around the appliance can withstand heat up to 200º F (93°C) generated by the
appliance. (See Figures 1 and 6)
•
Cabinet opening dimensions that are shown must be used. Given dimensions are minimum
clearances. (See Figures 1 and 6)
•
Working areas adjacent to the range should have 18″ minimum clearance between countertop
and cabinet bottom. (See Figures 1 and 6)
19
