Parts Supplied
Remove parts from packages. Check that all parts are included.
• Range hood (main core) with damper, blower, and LED lights installed
• Metal filters
• Inner chimney (upper vent cover)
• Outer chimney (lower vent cover)
• Range hood (main core) mounting bracket
• Inner chimney support bracket
• Outer chimney support bracket
• 6" round aluminum duct
• Oil tray (not included for Models: COS-6324EWH, COS-63024P)
• 4 x 30 mm mounting screws (11)
• 3 x 10 mm screws (4)
• 8 x 35 mm wall anchors (11)
Optional Parts
To purchase these or any other accessories, please visit
www.cosmoappliances.com or reference the contact information at the end
of this manual.
• Charcoal filter kit
• Chimney (vent cover) extensions
NOTE:
• 27.5" chimney extensions replace the chimneys shipped with the
range hood.
