Cabinet Clearances
Given dimensions are minimum clearances.
Insert Range Hood
IMPORTANT:
12 in
(30.5 cm)
Overhead
Cabinet
Depth
36 in
(91.4 cm)
18 in
(45.7 cm)
25.6 in
(65.0 cm)
A
Model A
30" Model: COS-30IRHP
36" Model: COS-36IRHP
• 25.6" (65.0 cm) minimum and 29.5" (75.0 cm) suggested maximum
clearances between cooking surface and bottom of the range hood or the
cabinet.
• For ducted wall venting installations using a 90° elbow, 12" (30.5 cm)
minimum overhead cabinet clearance below the wall venting opening is
required.
12 in
(30.5cm)
Overhead
Cabinet
Height
(Ductless)
27.8" (70.5 cm)
35.4" (90.0 cm)
