10
Operation
This will cycle the machine on and off. Upon cycling
power on, the machine will return to the settings it
had when it was cycled off.
If the replace is on, this button will act as a reset
and bring all colors back to the default orange color.
This will cycle the heater between high, low and off.
All zones of the replace will cycle through various
demo modes - 7 & 3 color gradient/fade, 7 & 3 color
jump, red/green/blue gradient.
Pressing the sync button will change all the colors of
the replace (Flame, Ember Bed and Downlight) to
match the current color of the ame setting.
This is a zone setting. Touching this button will allow
you to change the color and brightness of the ame
by using the color wheel and brightness slider.
This is a zone setting that controls the color and
brightness of the ember bed.
This is a zone setting that controls the color and
brightness of the downlight.
This will cycle the selected zone through the colors
of the color spectrum.
This will adjust the brightness of the selected zone.
The unit has a main power switch just in front of the glass on the right hand side. A
hand-held remote is included.
Power indicator lights for wall switch as well as upper right
corner of the main unit
When the switch turns on, this orange pilot lamp turns on. It
shows the re is energized.
The status light above shows that the power is on and the
heater is on low.
The status light above shows that the power is on and the
heater is on high.
Pairing remote:
1. With the replace ON press and hold the Power button for about
3 seconds until you hear the buzzer sound twice and the power
indicators begin to ash.
2. Within 5 seconds on the hand held remote or wall touch control
press the Power button repeatedly until the buzzer sounds again
and the indicators ash acknowledging that it has paired. You
may also hear another buzzer and the pair is now completed.
• Pairing must be done within 5 seconds or the replace will time
out of pairing mode.
• To clear any paired remotes from the unit, locate then press and
hold the reset button for 3 seconds. You should hear a buzzer
letting you know the codes have been cleared so you can now
pair a new remote or wall touch control. (The reset is located next
to the manual controls and can be pressed with a paper clip.)
Manual Controls
The unit has manual controls located next to
the power switch, just in front of the glass on
the top right side.
Power
Turns unit
on/off
Heat
Cycles heat
low/high/off
Color
Changes
replace
color
Reset
Resets unit
Downlight
Ember
Bed
Color
Wheel
Brightness
Slider
Fade
Flame
Heat
Reset
Power
Sync
