COSMOS - ALCOHOL - TESTER
GAS SIMULATOR
GEB-ANL. E Seite 09 b / 2005-04-02 / TYP 2000 E
COSMOS
ALCOHOL
TESTER
3 1 2
Blow here
Place the tipp in the
n
on-return valve of the
device
Inlet with bubbler
Gas simulator
Fill each time with 130 ml (maximum!!)
(With thermometer + bubbler = 140 ml)
Individual parts of the gas simulator
Bottle 250 ml
Screw top with insert and seal 217
Inlet PVC tube 05/07 14 cm
Outlet PVC tube 05/07 11 cm
Passage to
Bubbler PVC tube 07/10 3 cm
3 closures PVC tube 07/10 4 cm
against evaporation
2 droplet separators
1 thermometer + rubber bushing
1 bubbler
1 mouthpiece 07/10 4 cm
When blowing, the foam
m
ust not reach the outlet
hole!
1. Insert the thermometer into the
free hole (attach rubber bushing
first)
2. B
low-hole with protective cap
against evaporation (small tube
as 2
nd
mouthpiece).
3. Ou
tlet with three-chamber
system to hold back fluid.
IMPORTANT
Blowing in fluid interrupts the
ope
ration of the chemical cell for on
to three hours.
Leave the COSMOS ALCOHOL
TESTER switch
ed on. Moisture is
“burned off”.
Bubbler
The Cosmos Gas Simulator serves to simulate a human breath sample and therefore provides a low-
cost calibration procedure.
The gas simulator provides a controlled alcohol reference gas for the calibration of breath alcohol
measuring devices. Air is passed through an ethanol-in-water solution of a precisely known
concentration and temperature. The air absorbs ethanol and water vapour in a defined concentration
for the calibration of breath alcohol measuring devices.
The police also use the same electro-chemical measurement cell, among other things.
