COSMOS ALCOHOL TESTER TYPE 2000
Cable connections – display & computer
INSTRUCTIONS PAGE 05 / 2005-04-02 / TYPE 2000
1 brown
2 blue
2 pin socket
power supply
24 V
3pin socket /
loudspeaker
1 green
2 spare
3 green
Loudspeaker
Note the cut-out section!
COSMOS AUTOMATEN GMBH AM IHLSEE 18 D 23795 BAD SEGEBERG
Tel: 0049 (0) 4551/83838 Fax: 0049 (0) 4551/87171
1
2
3
4
4 pin socket with link
between channels 3 & 4
Straw moto
r
{
20-core cable connection to the
mother & display boards
20-core cable connection to the
display & additional boards
10-core cable connection to the
coin mechanism board
Connection to the
mother board
(note the cut-out
section)
Connection to the
additional board
(note the cut-out section)
{
Pump Moto
r
Connection to
the display
Connection to
the coin
mechanis
m
{
