Cosmos 2000 - Sound and Additional Boards; Sound Board Features; Additional Board Controls

COSMOS
ALCOHOL
TESTE
R
COSMOS-ALCOHOL-TESTER TYP 2000
SOUND & ADDITIONAL BOARD
This expansions module is not standard equipment
INSTRUCTIONS Page 13 / 02.04.05 / TYP 2000
Sound board
front
1
2
1 Recording button
2 Internal check
3 Microphone
3
back
P
1
Sound fast - slow
(sliding right increases the speed )
P
2
Loudspeaker volume control
(sliding left increases the volume)
P
3
Loudspeaker speech control
( sliding right increases the volume )
P
1
c
o
n
n
e
c
t
o
r
P
2
P
3
Additional board
from 1.5 %
0
from 3.0 %
0
from 5.0 %
0
R 6
R 5
R 4
COSMOS AUTOMATEN GMBH AM IHLSEE 18 23795 BAD SEGEBERG
Tel: 04551/83838 Fax: 04551/87171
