Cotes C35 - Page 29

COTES C35 OPERATING AND SERVICE HANDBOOK page 29/71
11
Heaters
111503
(6pcs)
111503
(6pcs)
111503
111504
(3+3pcs)
111504
(6pcs)
111506
(6pcs)
111503
(6pcs)
111504
(6pcs)
111503
(3pcs)
111504
(3pcs)
Configurations - B & C & D
Humidity sensor
(not shown)
140639
12
Pressure switch for filters
126843
13
Rotor guard
111597
14
PLC
140620
Configurations - C & D
15
I/O board
112086
16
Pressure switch for rotor
140624
Configuration - D
17
Process air in sensor
140625
18
Process air out sensor
140651
* Mounted externally before the duct heating element.
See the “How to install a C35C dehumidifier (Cold store model)” section for more details.
