COTES C35 OPERATING AND SERVICE HANDBOOK page 8/71
SECTION 2 / THE DEHUMIDIFIER
ABOUT THE COTES C35 RANGE OF DEHUMIDIFIERS
The Cotes C35 range of dehumidifiers is designed and configured for a wide range of industrial uses.
Prominent among these is humidity management in storage facilities and basement areas, in water
works and in many kinds of process industry in which stable, well-controlled air conditions are crucial.
C35E units are specifically configured to minimise the overall energy consumption of the
dehumidification process, whereas C35D units are configured to make sure the air flow is as dry as
possible. C35C units are specially designed to operate inside cold storage facilities.
The dehumidifiers in the C35 range are designed for easy cleaning, with configuration options that
include cooling/heating coils and/or a heat recovery module and a condensation module and
additional filters, if needed.
Design priorities
The Cotes C35 range features an eye-catching modern industrial design appearance, along with
exceptional reliability.
It is designed to ensure the unhindered passage of air through the unit, which reduces
• energy consumption
• pressure losses
• noise levels
All the components, ancillary equipment and features are optimised for better performance,
exceptional service life and ease of maintenance.
Capacities
The Cotes C35 range currently features models with air volumes of between 405 m
3
/hour and 1,000
m
3
/hour.
At process air inlet conditions of 20°C and 60% relative humidity (%RH), the capacities (the amount
of water which can be removed from the air) of these units are between 3.3 kg/hour and 5.6 kg/hour.
At process air inlet conditions from -25°C to -18°C and 95% relative humidity (%RH), the capacities
(the amount of water which can be removed from the air) of these units are between 0.3 kg/hour and
0.9 kg/hour.
