Coway CHP-06EL Service Manual

Exploded view of the system and the list of service parts
Coway co., Ltd
6-2
No Description
1 Tray grille
2 Tray
3 Front lower cover assy
4 Front middle assy
5 Front upper assy
6 Cock bracket assy
7 Neo Sense filter 14 inch
8 Membrane filter(RO)14 inch
9 Post Carbon comple x filter 14 inch
10 Filter bracket assy
11
Drain connector assy
12 Main PBA assy
13 Caster
14 Base plate
15 Booster pump
No Description
16 Compressor
17 Side cover R assy
18 Rear cover
19 Wire condenser
20 SMPS assy
21 Band heater
22 Hot water tank bracket
23 Main tank assy
24 Main tank insulation-Rear
25 Separate board
26 Main tankcap assy
27 Top cover assy
28 Main tank insulation-Front
29 Side cover L assy
