Coway CHP-06EL Service Manual

Exploded view of the system and the list of service parts
6-3
Coway co., Ltd
6-2 Service parts list of CHP-06EL
Code No. Description Specification Q’ty Remark
100754 Neo Sense filter 14 inch For export production 1
100777 Membrane filter (RO) 14 inch
For export production, normal 50 GPD,
melt-bonding type
1
100770 Post Carbon complex filter 14 inch
For export production, general
activated carbon
1
3002262
Filter drier
(CHP-8500, water purifying system)
Φ19 (XH-9i108) 1
3015129
NBR hose
(CHP-02C, water purifying system)
ID9xOD18x80L 1
3016359 Tap hose assy II 1M, for water extraction (common use) 1
3003795
Clip stopper
(CHP-8500, water purifying system)
ABS 2
3300165 Daily life water valve (GRAY) GRAY 1
3105797 Compressor (NS24LBAG)
R134a,100V,50/60Hz,1/12HP,
Pipe bending
1
3105798 Base plate assy (CHP-06E) Base assy 1
3202222 Caster (CHP-06E)
LG HF-380G/8J413B, Φ100x25,
Bolt M10x25 (Pitch 1.5)_insert
4
3106222
Front lower cover assy
(CHP-06E, English)
Assy 1
3107918
Front middle assy (CHP-06E, For Iran) Assy 1
3105802 Front upper assy (CHP-06E) Assy 1
3105803 Tray (CHP-06E) LG HF-380G/8J413B (GRAY) 1
3105804 Drain bracket (CHP-06E) GP-22 (M4 insert) 1
3106683
Main PBA assy (CHP-06E, export) Assy 1
3105806 Side cover L assy (CHP-06E) Assy 1
3105807 Side cover R assy (CHP-06E) Assy 1
3103060 Cooling coil assy (CHPE-04CL)
Flange connection material PBT, neck
length 17mm, suction part 556mm
1
3106254
Hot water tank assy (CHP-06E, export) Assy 1
3106684
Power cord (for CHP-06E, CE) 1
3105810 Power cord connection cable UL1015 20AWG 420mm/360mmX2 1
3105811 FEED-NOS valve (CHP-06E)
Assy, 24VDC, 10W, connecting part
change
1
3105812 Cock bracket (CHP-06E) 1t, electro coating 1
3105813 Main tank assy (CHP-06E) Assy 1
3105814 Rear cover (CHP-06E) LG HF-380G/07497B 1
3001797
Separate board
(CHPE-04CL, common use)
PP (JI360) 1
CHP-06EL-eng.indb 3 2007-10-19 ｿﾀﾈﾄ 1:04:36
