3105815 Top cover assy (CHP-06E) Assy 1
3105818 Main tank insulation-Front (CHP-06E) - 1
3105819 Main tank insulation-Rear (CHP-06E) - 1
3002257 Silicon hose-M/T-H/T (CHP-8500) Φ13xΦ17x475L,WHITE 1
3001086 Silicon hose-M/T-M/T (CHP-8500) U TYPE,Φ8XΦ11X345L 1
3105822
Silicon hose-M/T-COCK
(CHP-06E,White)
L TYPE D1(Φ11/Φ15)X
D2 (Φ14/Φ18) x129L,WHITE
1
3105823
Silicon hose-C/T-COCK
(CHP-06E,White)
D1 (Φ11/Φ15)X D2 (Φ19/Φ23)
x48.5L,WHITE
1
3105824
Silicon hose-H/T-COCK
(CHP-06E,White)
L TYPE D1(Φ8.5/Φ12)X
D2 (Φ18/Φ22) x148.5L,WHITE
1
3105825 Capillary tube (CHP-06E) Φ1.8xΦ0.7x1540 1
3105826 Suction pipe (CHP-06E) Φ6.35 x t0.6 1
3103059 NBR hose-C (CHPE-04CL) Φ18xΦ9x480L,ROO 1
3105827 Hot water tank bracket (CHP-06E) 1.2T 1
3105828 Reed level sensor (CHP-06E) Water level sensor Step 1 1
3105829 Full water level sensor (CHP-06E) Water level sensor Step 1 1
3106414
Compressor cable assy
(CHP-06E, For Iran)
Assy (outsourcing) 1
3105835 Wire condenser (CHP-06E) Φ4.76x0.7t,6Pitch 1
3002402 Ceramic filter (P-02A, common use) For production, common use 1
3105836 Main tank cap assy (CHP-06E) Assy 1
3105837 Filter bracket assy (CHP-06E) Assy 2
3105838 Cold cock assy (CHP-06E, export) Assy 1
3202254 Lever rubber (CHP-06E) SILICON, BLACK (hardness 50) 1
3105839 SMPS assy (CHP-06EL) 10W assy, CHP-06EL 1
3105841
Base connector assy - hot water
(CHP-06E)
Assy 1
3105842
Hot water safety cock assy
(CHP-06E, export)
One touch 1
3330000 Installation adaptor 1/2 inch Plastic 1/2 inch, for export 1
3105852 Grille (CHP-06E) LG HF-380G/8J413B(GRAY) 1
3105844 Cold water sensor assy (CHP-06E) Assy (outsourcing) 1
3000464 Tubing orange (common use, 1/4 inch) LLDPE,1/4 (Shinwon, DMT) 3.06
3000463 Tubing blue (common use, 1/4 inch) LLDPE,1/4 (Shinwon, DMT) 0.48
3016429 Press sealant (50X20X2T,BR) 50X20X2T 3
3016428 Overflow sensor (CHPE-04CL) Ti-Pt plating 2
3105845 Overflow sensor cable (CHP-06E) UL 1007 22AWG, ORANGE, 580mm 1
Code No.
Description Specification
Q’ty
Remark
To Next Page
