Parts location diagrams

7-8

Coway co., Ltd

7-4-2 BUTTON SWITCH

1 CN1(KEY ↔ MAIN)

Pin No. Signal

1 Signal (HOT S/W)

2 Signal (COLD S/W)

3 GND
