Coxo CX235 - Cartridge Removal (Specific Models)

Slit
Fig.14.1 Fig.14.2 Fig. 14.3 Fig. 14.4
1.2.Removal of the cartridage(CX235CH-11)
Loosen the curving lock section and remove the head from the sheath.
Pull out the drive gear assembly from the head.[Fig.14.1]
Directly remove the cartridge.[Fig.14.4]
2 2
(CX235CH-10)
(CX235C6-19)
(CX235-1F)
Fig.14.5 Fig.14.6
