COZY CDV155C - Page 23

1017757-CPage 23
PART DESCRIPTION
REF. #
34 Pilot Burner Q350A2501 - Propane Gas
70008 70008
35 Electrode 70052 70052
36 Electrode Wire 70051 70051
37 Piezo Sparker 80016 80016
38 Piezo Sparker Bracket 43263 43263
39 Valve, MV - Natural Gas 84085 84085
39 Valve, MV - Propane Gas 84086 84086
40 Pilot Generator, Q313A1014 MV 70098 70098
41 Pilot Tubing w/ Fittings 70012 70012
42 Thermostat, MV 74592 74592
N/A Thermostat Wire 74518 74518
N/A Insulated Staples 74209 74209
61 Gasket, Air Pan Top & Bottom
(15-1/4 x 1)
°°
70074
°°
70074
62 Gasket, Air Pan Sides (25 x 1)
°°
70073
°°
70073
56 90 Degree Elbow 70352 70352
N/A Vent Terminal Shield 34950 34950
46 Blower Housing w/ Motor & Blower 70201 70201
47 Junction Box 43610 43610
48 Junction Box Cover 43620 43620
50 Fan Switch 120 Degree 70110 70110
51 Cord Set 80202 80202
N/A Cover Plate 43078 43078
N/A Blower Shield 43625 43625
N/A LeftAirIntakeBafe 43528 43528
N/A RightAirIntakeBafe 43526 43526
DIRECT VENT WALL FURNACE PARTS LIST
Natural Gas: CDV255C & CDV335C | Propane Gas: CDV256C & CDV336C
ATTN: Contractors and Qualified Service Technicians: We only sell parts through our wholesalers.
For prompt parts service, contact the wholesaler from which you purchased your Cozy heater.
PART DESCRIPTION
REF. #
1 Heat Exchanger Kit, Includes: *42770 *42770
- Wrapper (Ref. #2)
- Right And Left Leg (Ref. #s 6 & 7)
- Comb. Air Pan Assembly W/Gaskets (Ref. #63)
3 Cabinet 42755 42755
6 Leg, Right 43495 43495
7 Leg, Left 43494 43494
9 Front Heat Shield Assembly 43481 43481
10 Bottom Heat Shield Assembly 43473 43473
11/12 Vent Cap W/ Spacer Plate 43145 43145
15 Air Intake Tube Assy. 5” – 9” Wall 43200 43200
16 Air Intake Tube Assy. 9” – 15” Wall 43810 43810
58 Air Intake Tube Assy. 15” – 24” Wall 43705 N/A
17 Air Intake Tube Gasket 8-1/2” Circle 70061 70061
18 Vent Exhaust Tube Assy. (5” – 9” Wall) 43530 43538
19 Vent Exhaust Tube Assy. (9”– 5” Wall) 43820 43828
59 Vent Exhaust Tube Assy. (15” – 24” Wall) 43717 N/A
20 Vent Exhaust Tube Gasket: Requires 4
5-3/8” Circle 70062 70062
21 Wall Thimble: (5” – 9” Wall) 43552 43552
22 Wall Thimble Ext. (5” – 9” Wall) 43236 43236
23 Wall Thimble Ext. (9” – 15” Wall) 43835 43835
60 Wall Thimble Ext. (15” – 24” Wall) 43730 N/A
24 Wall Thimble Gasket - 11” x 11” 70066 70066
25 Burner Access Door 43247 43247
26 Burner Access Door Gasket
5-1/2” x 11-3/8” 70060 70060
27 Burner 70006 70006
28 Manifold 70032 70032
29 Manifold Gasket - 2” x 2” 70065 70065
30 MainBurnerOrice (Nat. Gas) 70048 70047
30 MainBurnerOrice- Propane Gas 70039 70049
31 Sight Glass 43252 43252
32 Sight Glass Cover 43258 43258
33 Gasket, Sight Glass/Pilot Burner
3-1/2” x 2-3/4” 70064 70064
34 Pilot Burner Q350A2493 - Nat. Gas 70007 70007
HOW TO PROPERLY ORDER PARTS:
In addition to the part description and numbers,
please be prepared to provide:
- Model Number
- Serial Number
- Type of Gas Used
This information can be found on the
rating plate that is attached to the heater.
PART NO.PART NO. PART NO.PART NO.
*Kit contents are not sold independently.
°°
Requires 2
NOTE: Parts & schematic drawings on current models are shown at: cozyheaters.com | Specications subject to change without notice.
