PARTS DIAGRAM
# ITEM NUMBER DESCRIPTION QTY
1 351302250132 BURNER GRATE 6
2 351128051028 BURNER ASSEMBLY (SHORT) 3
3 351128051027 BURNER ASSEMBLY (LONG) 3
4 35128077006 FRAME ASSEMBLY 1
5 35128051009 GAS CONTROL ASSEMBLY 1
6 351228051005 FRONT CONTROL VALVE 1
7 351202230111
BURNER KNOB 6
BURNER KNOB CORE 6
8 351301130111
OVEN KNOB 1
OVEN KNOB CORE 1
9 35128077010 SIDE PANEL (LEFT) 1
10 35128051005 OVEN DOOR ASSEMBLY 1
11 351228051031 32” KICK PLATE 1
12 351302140137 ORIFICE ELBOW 1
13.a 351302150198 ORIFICE #36 - OVEN NAT 1
13.b 351302150189 ORIFICE #50 - OVEN LP 1
14 351302170058 THERMOCOUPLE 1
15 351302130384 OVEN TUBE BURNER 1
16
351302090149 ADJUSTABLE LEG 4
351190487 LEG MOUNTING PLATE 4
17 35128077013 SIDE PANEL (RIGHT) 1
18.a 351302130427 PILOT OVEN NAT 1
18.b 351302130447 PILOT OVEN LP 1
19 35128051004 OVEN TANK ASSEMBLY 1
20 351228051012 CRUMB TRAY 31” X 32” 1
21 351128051007 INNER FLUE ASSEMBLY 1
22 351228051044 SLIDE RAIL (REAR BAFFLE) 2
23 351228046015 GAS PIPE (PILOT) (SHORT BURNER) 3
24 351228046016 GAS PIPE (PILOT) (LONG BURNER) 3
25 351302130019 STOVE PILOT 6
26 351302060231 PIPE FIXER 1
27 351128051006 BACK PANEL ASSEMBLY 1
28* 351302140195 BRASS FITTING (THERMOCOUPLE) 1
29* 351228080018 THERMOCOUPLE PLATE 1
30* 351050081 EXTERNAL REGULATOR 1
31* 351302090155 CASTER W/BRAKE OPTIONAL
32* 351302090156 CASTER W/NO BRAKE OPTIONAL
33* 351CASTER4 CASTER SET OF 4 OPTIONAL
*NOT SHOWN IN DIAGRAM
