USER MANUAL
31 www.CookingPerformanceGroup.com
PARTS DIAGRAM
# ITEM NUMBER DESCRIPTION QTY
1 35128059009 REAR SHROUDING ASSEMBLY 1
2 35128051014 OVEN TANK TOP PLATE 1
3 35128051023 SENSOR FIXED PLATE 1
4 35128058010 OVEN TANK LEFT PLATE 1
5 35128051020 OVEN TANK BOTTOM LEFT LIMIT PLATE 1
6 35128058015 OVEN TANK SIDE REINFORCE PLATE 2
7 35128051018 OVEN TANK LOWER FRONT PLATE 1
8 351302110504 RACK HOLDER 2
9 351302110503 RACK 26” X 24.5” (OVEN CHAMBER) 2
10 351428051001 BASEBOARD (CHAMBER) 1
11 35128051028 OVEN TANK BOTTOM REINFORCE PLATE 1
12 351302190429 DOOR HINGE - SEAT 2
13 35128051021 OVEN TANK BOTTOM LEFT RIGHT PLATE 1
14 35128058011 OVEN TANK RIGHT PLATE 1
OVEN TANK
ASSEMBLY
8
To Next Page
