PARTS DIAGRAM
# ITEM NUMBER DESCRIPTION QTY
1 316130010 REAR PANEL (BACK) 1
2 20228051041 DECORATION COVER 1
3 20228051038 FRONT PANEL (BACK) 1
4 20128051007 INNER FLUE ASSEMBLY 1
5 316130004 SLIDE RAIL (REAR BAFFLE) 2
6 302010502 GRIDDLE PLATE ASSEMBLY 1
7 20228077013 RIGHT SIDE PANEL 1
8 20228077011 FLUE SHEET (GRIDDLE) 1
9 20228076011 FLUE SHEET (GRIDDLE) 1
10 20228076004 CHAMBER BASEBOARD(GRIDDLE) 1
11 20128051004 LINER ASSEMBLY (OVEN) 1
12 20128078006 OIL PAN ASSEMBLY 2
13 302110503 CHAMBER RACK (OVEN) 2
14 302090158 ADJUSTABLE LEG 4
15 20228051029 BASEBOARD (HOUSING) 1
16 316130001 LOWER FRONT SLAB 1
17 302130384 BURNER 1
18 302130427 PILOT (NG) 1
19 302130447 PILOT RACK (LP) 1
20 302150132 NOZZLE 1
21 20128051005 DOOR ASSEMBLY 1
22 302070144 DOOR HANDLE 1
23 301110527 KNOB ASSEMBLY 5
24 20228077010 LEFT SIDE PANEL 1
25 302190497 BASEBOARD (OVEN CHAMBER) 1
26 302110504 RACK HOLDER 2
27 301110500 KNOB 1
28 20228058007 CRUMB TRAY 1
29 20228076003 FRONT CONTROL PANEL 1
30 20228076001 BASEBOARD 1
31 302220028 NG/LPG REGULATING VALVE 1
32 302220027 NG/LPG REGULATING VALVE 2
33 302050051 VALVE 5
34 302180623 GAS INLET PIPE ASSEMBLY 1
35 302150132 NOZZLE 4
36 302150132 NOZZLE 1
37 302250166 SHORT BURNER ASSEMBLY 2
38 302220127 RELIEF VALVE 1
39 302250165 LONG BURNER ASSEMBLY 2
40 302250132 GRATE 4
41 302130387 BURNER 1
42 20228051079 STRENGTHENING PLATE 2
43 302140137 ELBOW 1
