USER MANUAL
36 www.CookingPerformanceGroup.com
PARTS DIAGRAM
# ITEM NUMBER DESCRIPTION QTY
1 20228051019 REAR SHROUDING 1
2 20228051014 TOP PANEL (OVEN CHAMBER) 1
3 314490021 FIXED PLATE (TEMP. SENSOR) 1
4 20228051015 LEFT SIDE PANEL (OVEN CHAMBER) 1
5 316130002 BASEBOARD RETAINER (LEFT) 1
6 20228051026 STRENGTHENING PLATE (SIDE PANEL) 2
7 302110504 RACK BRACKET 2
8 302110503 RACK(OVEN CHAMBER) 2
9 20228051018 LOWER FRONT PANEL 1
10 302190497 BASEBOARD (OVEN CHAMBER) 1
11 20228051028 STRENGTHENING PLATE (BASEBOARD) 1
12 302190429 DOOR HINGE 2
13 316130007 BASEBOARD RETAINER (RIGHT) 1
14 20228051016 RIGHT SIDE PANEL (OVEN CHAMBER) 1
OVEN TANK ASSEMBLY
