PARTS DIAGRAM
# ITEM NUMBER DESCRIPTION QTY
1 20228051039
REAR PANEL (BACK) 1
2 20228051038
FRONT PANEL (BACK) 1
3 20228051044
SLIDE RAIL (REAR BAFFLE) 2
4 20128051007
INNER FLUE ASSEMBLY 1
5 20228051040
BRACE (BACK PANEL) 2
6 20128077005
FRAME ASSEMBLY (GRIDDLE) 1
7 302010497
GRIDDLE PLATE ASSEMBLY 1
8
20228077013
RIGHT SIDE PANEL 1
9 302130387
GRIDDLE BURNER 2
10 20228077016
CRUMB TRAY 1
11 20128051004
LINER ASSEMBLY (OVEN) 1
12 20128078006
DRIP PAN ASSEMBLY 1
13 302090158
ADJUSTABLE LEG 4
14 302190497
BASEBOARD (OVEN CHAMBER) 1
15 302150132
OVEN ORIFICE 1
16 20228051031
LOWER FRONT BEAM 1
17 20228051033
EXTERIOR PLATE( WITH LOGO HOLE) 1
18 302070144
DOOR HANDLE 1
19 302130427
PILOT (NG) 1
302130447
PILOT (LPG) 1
20 302130384
OVEN BURNER 1
21 302110504
RACK HOLDER 2
22 302110503
RACK (OVEN CHAMBER) 2
23 301110500
OVEN KNOB 1
24 20228077007
FRONT CONTROL PANEL 1
25 20228077006
FRONT COUNTERTOP 1
26 301110527
STOVE& GRIDDLE KNOB 4
27 20228077005
CRUMB TRAY 1
28 20228077010
LEFT SIDE PANEL 1
29 302250166
SHORT BURNER ASSEMBLY 1
30 302220127
GAS VALVE 1
31 302150132
GRIDDLE NOZZLE 2
32 302220027
NG/LPG REGULATING VALVE
1
33 302050051
PB100 VALVE 4
34 302150132
STOVE NOZZLE 2
35 302180441
GAS INLET PIPE ASSEMBLY 1
36 302220027
NG/LPG REGULATING VALVE AP7-1 2
37 302250165
LONG BURNER ASSEMBLY 1
38 302250132
BURNER GRATE 2
39 20228077012
FLUE SHEET (GRIDDLE) 1
40 20228077011
FLUE SHEET (GRIDDLE) 1
