PARTS DIAGRAM
*NOT SHOWN IN DIAGRAM
# ITEM NUMBER DESCRIPTION QTY
1 351302250132 BURNER GRATE 6
2 35128051028 BURNER ASSEMBLY (SHORT) 3
3 35128051027 BURNER ASSEMBLY (LONG) 3
4 35128069003 GAS CONTROL ASSEMBLY 1
5 35128078022 SIDE PANEL (LEFT) 1
6 35128059001 FRONT COUNTERTOP 1
7 35128078005 FRONT CONTROL PANEL 1
8 351202230111
BURNER KNOB 8
BURNER KNOB CORE 8
9 351301130111
OVEN KNOB 2
OVEN KNOB CORE 2
10 35128059005 DOOR EXTERIOR PLATE (WITHOUT LOGO HOLE) 2
11 351228059011 30” KICK PLATE 2
12 35128078006 GREASE TRAY 8” X 3” 1
13 351302140137 ORIFICE ELBOW 2
14.a 351302150198 ORIFICE #36 - OVEN NAT 2
14.b 351302150189 ORIFICE #50 - OVEN LP 2
15 351302170058 THERMOCOUPLE 2
16.a 351302130427 OVEN PILOT NAT 2
16.b
351302130447 OVEN PILOT LP 2
17 351302130384 OVEN TUBE BURNER 2
18 351302090149 ADJUSTABLE LEG 6
19 351190487 LEG MOUNTING PLATE 6
20 35128059004 OVEN TANK ASSEMBLY 2
21 35128078024 SIDE PANEL (RIGHT) 1
22 351302130387 U-SHAPED GRIDDLE BURNER 2
23 351302010497 GRIDDLE PLATE ASSEMBLY 1
24 35128078023 GRIDDLE FLUE SHEET (LONG) 1
25 35128077011 GRIDDLE FLUE SHEET (SHORT) 1
26 35128059006 BACK PANEL ASSEMBLY 1
27* 351228051012 CRUMB TRAY 31” X 32” 1
28* 351228077016 CRUMB TRAY 19” X 7” 1
29* 351302140195 BRASS FITTING (THERMOCOUPLE) 1
30* 351228080018 THERMOCOUPLE PLATE 1
31* 351050081 EXTERNAL REGULATOR 1
32* 351302090155 CASTER W/BRAKE OPTIONAL
33* 351302090156 CASTER W/NO BRAKE OPTIONAL
34* 351CASTER6 CASTER SET OF 6 OPTIONAL
