USER MANUAL
48 www.CookingPerformanceGroup.com
PARTS DIAGRAM
# ITEM NUMBER DESCRIPTION QTY
1 351302250132 BURNER GRATE 6
2 351128051027 BURNER ASSEMBLY (LONG) 3
3 351128051028 BURNER ASSEMBLY (SHORT) 3
4 35128079003 GAS CONTROL ASSEMBLY 1
5 35128078022 SIDE PANEL (LEFT) 1
6 35128077006 FRONT COUNTERTOP 1
7 35128079003 FRONT CONTROL PANEL 1
8 351202230111
BURNER, GRIDDLE, & SALAMANDER KNOB 9
BURNER, GRIDDLE, & SALAMANDER KNOB CORE 9
9 351301130111
OVEN KNOB 2
OVEN KNOB CORE 2
10 35128059005 DOOR EXTERIOR PLATE 2
11 351228059011 30” KICK PLATE 2
12 35128079008 GREASE TRAY 28” X 3” 1
13 351302170058 THERMOCOUPLE 2
14 351302140137 ORIFICE ELBOW 2
15.a 351302150198 ORIFICE #36 - OVEN NAT 2
15.b 351302150189 ORIFICE #50 - OVEN LP 2
16 351302130384 OVEN TUBE BURNER 2
17.a
351302130427 OVEN PILOT NAT 2
17.b 351302130447 OVEN PILOT LP 2
18 351302090149 ADJUSTABLE LEG 6
19 351190487 LEG MOUNTING PLATE 6
20 35128079035 SIDE PANEL (RIGHT) 1
21 35128079005 SALAMANDER FRAME 1
22* 351228051012 CRUMB TRAY 31” X 32” 1
23* 351302140195 BRASS FITTING (THERMOCOUPLE) 1
24* 351228080018 THERMOCOUPLE PLATE 1
25* 351050081 EXTERNAL REGULATOR 1
26* 351302090155 CASTER W/BRAKE OPTIONAL
27* 351302090156 CASTER W/NO BRAKE OPTIONAL
28* 351CASTER6 CASTER SET OF 6 OPTIONAL
*NOT SHOWN IN DIAGRAM
