TECHNICAL DATA TD-9
Torques:
[∅ mm]
[Nm]
Front axle nut 12 55
Rear axle nut 14 120
Screw front fork bridge 10 30
Screw brake calliper 8 40
Screw handle bar 10 50
Shock absorber lower fixing 8 25
Engine mounting screw 10 50
12 55
Gearbox cover screw 8 20
Crankcase 6 10
Cylinder head 7 12
Flywheel 10 35
CVT fixing nut 10 35
Clutch fixing nut 10 45
Clutch pads fixing nut 28 45
Drain plug gearbox 8 15
CVT cover 6 12
Kick starter 6 12
Exhaust pipe 6 10
Silencer 8 30
Standard torque for 12 60
screws and nuts without 10 40
special function 8 25
6 12
5 4
Spark plug 14 15
Electrical assy:
Battery charging voltage
(Battery fully charged)
13,5 +
0,5 [V]
Battery charging current
(Battery empty)
1,8 [A]
Fuse 8 [A]
Bulb low beam
Bulb high beam
Bulb position lamp
55 H1
55 H1
5
[W]
Bulb rear- and stop lamp, License plate illumination 21 / 5 [W]
Bulb winker LED [W]
Ignition pulse generator (blue/white-green/white) 340 ± 50
1,5 / 1900
[Ω]
[V/ min
-1
]
Ignition coil ACG
900 ± 100
125 / 800
[Ω]
[V/ min
-1
]
Charging coil (white)
Plug disconnected
Max. voltage
0,9
22 / 2500
81 / 8500
[Ω]
[V/ min
-1
]
[V/ min
-1
]
Light coil (green/white)
Plug disconnected
Max. voltage
0,8
18 / 2500
69 / 8500
[Ω]
[V/ min
-1
]
[V/ min
-1
]
Ignition coil primary 0,4 – 0,6
[Ω]
Ignition coil secondary
3 ± 0,5
[kΩ]
Spark plug connector 10
[kΩ]
Spark plug BR7ES [---]
Spark plug gap 0,7 – 0,8 [mm]
Spark gap min.6 [mm]
Ignition point 17 / 1800 [°/min
-1
]
Distance between pickup and flywheel 0,6 – 0,8 [mm]
